[RS]ZigZag (MA, Pattern Recognition) V2 — Petunjuk oleh RicardoSantos

experimental zigzag harmonicpatterns zigzagindicator

EXPERIMENTAL:
Best method so far to draw the zigzag.
Multi time frame options

Skrip sumber terbuka

Dalam semangat TradingView yang sebenar, penulis skrip ini telah menerbitkannya dengan menggunakan sumber terbuka supaya pedagang-pedagang dapat memahami dan mengesahkannya. Sorakan kepada penulis! Anda dapat menggunakannya secara percuma tetapi penggunaan semula kod ini dalam penerbitan adalah dikawalselia oleh Peraturan Dalaman. Anda boleh menyukainya untuk menggunakannya pada carta.

Penafian

Maklumat dan penerbitan adalah tidak dimaksudkan untuk menjadi, dan tidak membentuk, nasihat untuk kewangan, pelaburan, perdagangan dan jenis-jenis lain atau cadangan yang dibekalkan atau disahkan oleh TradingView. Baca dengan lebih lanjut di Terma Penggunaan.

Ingin menggunakan skrip ini pada carta?

study("[RS]ZigZag (MA, Pattern Recognition) V2", overlay=true)
length = input(4)
ExtremeDetection = input(4)
useAltTF = input(true)
AlternativeTF = input('15')
showChannel = input(true)

f_zz(_length, _detection)=>
    _hls = ema(ema(ema(hl2, _length), round(_length*0.66)), round(_length*0.33))
    _isRising = _hls >= _hls[1]
    _zigzag = _isRising and not _isRising[1] ? lowest(_detection) :  not _isRising and _isRising[1] ? highest(_detection) : na

zigzag = useAltTF ? (change(time(AlternativeTF)) != 0 ? security(tickerid, AlternativeTF, f_zz(length, ExtremeDetection)) : na) : f_zz(length, ExtremeDetection)
tops = valuewhen(zigzag, zigzag, 0) >= valuewhen(zigzag, highest(ExtremeDetection), 0) and zigzag ? valuewhen(zigzag, zigzag, 0) : na
bottoms = valuewhen(zigzag, zigzag, 0) <= valuewhen(zigzag, lowest(ExtremeDetection), 0) and zigzag ? valuewhen(zigzag, zigzag, 0) : na

plot(not showChannel ? na : tops, color=black)
plot(not showChannel ? na : bottoms, color=black)
plot(zigzag, color=black, linewidth=2)
//  ||---   Pattern Recognition:


//istop() => zigzag == filteredtopf
//isbot() => zigzag == filteredbotf

x = valuewhen(zigzag, zigzag, 4)
a = valuewhen(zigzag, zigzag, 3)
b = valuewhen(zigzag, zigzag, 2)
c = valuewhen(zigzag, zigzag, 1)
d = valuewhen(zigzag, zigzag, 0)

xab = (abs(b-a)/abs(x-a))
xad = (abs(a-d)/abs(x-a))
abc = (abs(b-c)/abs(a-b))
bcd = (abs(c-d)/abs(b-c))

//  ||-->   Functions:
isBat(_mode)=>
    _xab = xab >= 0.382 and xab <= 0.5
    _abc = abc >= 0.382 and abc <= 0.886
    _bcd = bcd >= 1.618 and bcd <= 2.618
    _xad = xad <= 0.886
    _xab and _abc and _bcd and _xad and (_mode == 1 ? d < c : d > c)

isAltBat(_mode)=>
    _xab = xab <= 0.382
    _abc = abc >= 0.382 and abc <= 0.886
    _bcd = bcd >= 2.0 and bcd <= 3.618
    _xad = xad <= 1.13
    _xab and _abc and _bcd and _xad and (_mode == 1 ? d < c : d > c)

isButterfly(_mode)=>
    _xab = xab <= 0.786
    _abc = abc >= 0.382 and abc <= 0.886
    _bcd = bcd >= 1.618 and bcd <= 2.618
    _xad = xad >= 1.27 and xad <= 1.618
    _xab and _abc and _bcd and _xad and (_mode == 1 ? d < c : d > c)

isABCD(_mode)=>
    _abc = abc >= 0.382 and abc <= 0.886
    _bcd = bcd >= 1.13 and bcd <= 2.618
    _abc and _bcd and (_mode == 1 ? d < c : d > c)

isGartley(_mode)=>
    _xab = xab >= 0.5 and xab <= 0.618 // 0.618
    _abc = abc >= 0.382 and abc <= 0.886
    _bcd = bcd >= 1.13 and bcd <= 2.618
    _xad = xad >= 0.75 and xad <= 0.875 // 0.786
    _xab and _abc and _bcd and _xad and (_mode == 1 ? d < c : d > c)

isCrab(_mode)=>
    _xab = xab >= 0.75 and xab <= 0.875 // 0.886
    _abc = abc >= 0.382 and abc <= 0.886
    _bcd = bcd >= 2.0 and bcd <= 3.618
    _xad = xad >= 1.5 and xad <= 1.625 // 1.618
    _xab and _abc and _bcd and _xad and (_mode == 1 ? d < c : d > c)

isShark(_mode)=>
    _xab = xab >= 0.5 and xab <= 0.875 // 0.886
    _abc = abc >= 1.13 and abc <= 1.618
    _bcd = bcd >= 1.27 and bcd <= 2.24
    _xad = xad >= 0.88 and xad <= 1.13
    _xab and _abc and _bcd and _xad and (_mode == 1 ? d < c : d > c)

is5o(_mode)=>
    _xab = xab >= 1.13 and xab <= 1.618
    _abc = abc >= 1.618 and abc <= 2.24
    _bcd = bcd >= 0.5 and bcd <= 0.625 // 0.5
    _xad = xad >= 0.0 and xad <= 0.236 // negative?
    _xab and _abc and _bcd and _xad and (_mode == 1 ? d < c : d > c)

isWolf(_mode)=>
    _xab = xab >= 1.27 and xab <= 1.618
    _abc = abc >= 0 and abc <= 5
    _bcd = bcd >= 1.27 and bcd <= 1.618
    _xad = xad >= 0.0 and xad <= 5
    _xab and _abc and _bcd and _xad and (_mode == 1 ? d < c : d > c)

plotshape(isABCD(-1) and not isABCD(-1)[1], text="\nAB=CD", style=shape.labeldown, color=maroon, textcolor=white, location=location.top, transp=0, offset=-2)
plotshape(isBat(-1) and not isBat(-1)[1], text="Bat", style=shape.labeldown, color=maroon, textcolor=white, location=location.top, transp=0, offset=-2)
plotshape(isAltBat(-1) and not isAltBat(-1)[1], text="Alt Bat", style=shape.labeldown, color=maroon, textcolor=white, location=location.top, transp=0)
plotshape(isButterfly(-1) and not isButterfly(-1)[1], text="Butterfly", style=shape.labeldown, color=maroon, textcolor=white, location=location.top, transp=0)
plotshape(isGartley(-1) and not isGartley(-1)[1], text="Gartley", style=shape.labeldown, color=maroon, textcolor=white, location=location.top, transp=0)
plotshape(isCrab(-1) and not isCrab(-1)[1], text="Crab", style=shape.labeldown, color=maroon, textcolor=white, location=location.top, transp=0)
plotshape(isShark(-1) and not isShark(-1)[1], text="Shark", style=shape.labeldown, color=maroon, textcolor=white, location=location.top, transp=0)
plotshape(is5o(-1) and not is5o(-1)[1], text="5-O", style=shape.labeldown, color=maroon, textcolor=white, location=location.top, transp=0)
plotshape(isWolf(-1) and not isWolf(-1)[1], text="Wolf Wave", style=shape.labeldown, color=maroon, textcolor=white, location=location.top, transp=0)

plotshape(isABCD(1) and not isABCD(1)[1], text="AB=CD\n", style=shape.labelup, color=green, textcolor=white, location=location.bottom, transp=0)
plotshape(isBat(1) and not isBat(1)[1], text="Bat", style=shape.labelup, color=green, textcolor=white, location=location.bottom, transp=0)
plotshape(isAltBat(1) and not isAltBat(1)[1], text="Alt Bat", style=shape.labelup, color=green, textcolor=white, location=location.bottom, transp=0)
plotshape(isButterfly(1) and not isButterfly(1)[1], text="Butterfly", style=shape.labelup, color=green, textcolor=white, location=location.bottom, transp=0)
plotshape(isGartley(1) and not isGartley(1)[1], text="Gartley", style=shape.labelup, color=green, textcolor=white, location=location.bottom, transp=0)
plotshape(isCrab(1) and not isCrab(1)[1], text="Crab", style=shape.labelup, color=green, textcolor=white, location=location.bottom, transp=0)
plotshape(isShark(1) and not isShark(1)[1], text="Shark", style=shape.labelup, color=green, textcolor=white, location=location.bottom, transp=0)
plotshape(is5o(1) and not is5o(1)[1], text="5-O", style=shape.labelup, color=green, textcolor=white, location=location.bottom, transp=0)
plotshape(isWolf(1) and not isWolf(1)[1], text="Wolf Wave", style=shape.labelup, color=green, textcolor=white, location=location.bottom, transp=0)
