NQ Statistical MapperNQ Statistical Mapper
CRITICAL DISCLAIMER - READ FIRST
WARNING: THIS INDICATOR IS EXCLUSIVELY FOR NQ (NASDAQ-100 E-MINI FUTURES) ONLY
All statistics displayed in this indicator are HARD-CODED values derived from a comprehensive analysis of 12 years (2013-2025) of 1-minute NQ futures data. These statistics are calculated offline using Python and embedded directly into the indicator code.
These probabilities DO NOT apply to any instrument other than NQ
What This Indicator Does
The NQ Statistical Mapper is a data-driven trading tool that displays historical probability statistics for intraday NQ price behavior based on overnight session structure and opening positioning. Rather than generating signals, it provides context by showing:
Three trading sessions with visual boxes: Asia (8PM-2AM), London (2AM-8AM), and New York (8AM-4PM) Eastern Time
Key price levels with historical hit rate percentages showing the probability these levels are touched during the NY cash session (8AM-4PM)
Context-aware statistics that change based on current market conditions
Session range analysis showing whether Asia and London ranges are unusually large or small compared to recent history
Core Methodology and Statistical Foundation
Pattern Detection System
The indicator automatically detects one of four overnight session patterns based on how the London session (2AM-8AM) interacts with the Asia session (8PM-2AM):
London Engulfs Asia: London high is greater than Asia high AND London low is less than Asia low
Asia Engulfs London: Asia high is greater than or equal to London high AND Asia low is less than or equal to London low
London Partial Up: London high is greater than Asia high BUT London low is greater than or equal to Asia low (took out Asia high only)
London Partial Down: London low is less than Asia low BUT London high is less than or equal to Asia high (took out Asia low only)
Each pattern has distinct statistical characteristics that influence NY session behavior.
Conditional Probability Framework
The indicator uses a conditional probability approach where statistics adapt based on:
Primary Condition: Where does NY open (8:00 AM) relative to the London session midpoint?
"NY opens above London midpoint"
"NY opens below London midpoint"
This single condition dramatically changes the probabilities. For example:
When NY opens above London midpoint: 76.68% chance NY hits the London high before the London low during 8AM-4PM
When NY opens below London midpoint: 73.32% chance NY hits the London low before the London high during 8AM-4PM
Secondary Condition: The overnight pattern further refines these probabilities. Each combination of "NY position vs London midpoint" plus "overnight pattern" has unique hit rate statistics calculated from the 12-year dataset.
"Hit First" Statistics Explained
The table displays "Hit High First" and "Hit Low First" percentages. These answer the question: "During the NY cash session (8AM-4PM), if price eventually touches both the London high AND London low, which one does it touch FIRST?"
Example interpretation:
Hit High First: 76.68% means that in 76.68% of historical days with this setup, price touched the London high before touching the London low
Hit Low First: 22.48% means London low was touched first
The remaining approximately 1% represents days where neither level was hit during the NY session
This is fundamentally different from asking "will price go up or down" - it is about the sequence of range expansion during the NY session.
Displayed Levels and Their Meanings
Session Highs/Lows (Solid Lines)
These appear when each session completes and extend through the NY session:
Asia High/Low (Orange): The highest and lowest prices during 8PM-2AM EST
London High/Low (Blue): The highest and lowest prices during 2AM-8AM EST
Each level shows its hit rate percentage - the probability that NY session price (8AM-4PM) will touch that level, based on the current pattern and NY opening position.
Hourly Midpoint Levels (Dashed Gray Lines)
Three specific hourly levels with remarkably high hit rates:
7-8 AM Midpoint: Average of high and low during the 7-8 AM hour. Hit rates consistently above 93-94%, essentially sitting at the 8 AM open price (mean distance: -0.001%)
Midnight Open: The opening price at midnight EST. Hit rates vary from 62-87% depending on pattern and setup
2-3 AM Midpoint: Average of high and low during the 2-3 AM hour. Hit rates range from 67-92%
These levels are derived from mean-reversion behavior - price tends to revisit certain overnight reference points during the NY session.
Session Midpoints (Dotted Lines)
Optional display of Asia and London session midpoints. These lines terminate when their respective sessions end, providing additional reference levels for session positioning.
Statistics Table Breakdown
The table displays five sections of information:
1. SETUP Section
Shows whether "NY opens above/below London midpoint"
Displays the detected overnight pattern (1 of 4 types)
Sample size: Number of historical days matching this exact setup
Hit High First / Hit Low First: Directional bias percentages
2. HIT RATES (8AM-4PM) Section
Shows probability that each level gets touched at any point during the NY cash session:
7-8 AM Midpoint: Almost always touched (93-97% depending on pattern)
Midnight Open: Varies significantly (62-87%) based on whether the overnight pattern is aligned or contrary to NY's opening position
2-3 AM Midpoint: Strong hit rates (67-92%)
These are independent probabilities - they do not predict which is hit first, just whether each level gets visited.
3. ASIA RANGE Section
Real-time comparison of today's Asia session range versus recent history:
Sessions Captured: Shows how many sessions are in the rolling calculation (e.g., "18 / 50" = 18 sessions captured out of 50 requested). This alerts users if their chart history is insufficient
Current Range: Today's Asia high minus Asia low in points
Mean Range: Average range over the captured sessions
Percentile Rank: Where today's range falls in the distribution
80th percentile (red background): Unusually large range - top 20% of days
60-80th percentile (light gray): Above average
20-60th percentile (white): Normal range
Less than 20th percentile (light blue): Unusually small range - bottom 20% of days
4. LONDON RANGE Section
Identical structure to Asia Range section, analyzing the London session's range characteristics.
Why Percentile Rank Instead of Standard Deviation?
Intraday ranges exhibit right-skewed distributions with fat tails (volatility spikes create extreme outliers). Percentile rank is distribution-free and robust to these characteristics, providing more reliable identification of unusual ranges than z-scores or standard deviations.
How To Use This Indicator
For Context and Confluence
This is not a standalone trading system. The indicator provides statistical context to support other analysis:
Understanding Session Bias: If the table shows 76% probability of hitting the session high first, you know there is a statistical lean toward upside range expansion
Target Setting: If trading a breakout above the overnight high, knowing that Asia high gets hit 75% of the time helps assess target viability
Entry Timing: The 7-8 AM midpoint's 94% hit rate makes it an excellent re-entry or scaling level
Range Expansion Assessment: Percentile rankings help identify whether overnight sessions showed abnormal volatility, which may influence NY session behavior
Pattern-Specific Insights
London Partial Up plus NY Opens Below London Midpoint:
Midnight open hit rate jumps to 87.82% (strong mean reversion)
Suggests counter-trend reversal back toward overnight lows is likely
London Partial Down plus NY Opens Above London Midpoint:
Midnight open hit rate is 86.30%
Mirror pattern - reversion toward overnight highs
Asia Engulfs London Pattern:
Very high hit rates (85-98%) across all levels
Suggests consolidation/mean reversion during NY session rather than directional expansion
Typical Workflow
8:00 AM: Review the statistics table - which pattern occurred? Where did NY open relative to London midpoint?
Check Hit Rates: Note which levels have the highest probabilities of being touched
Assess Range Percentiles: Are Asia/London ranges unusually large or small? High percentiles may indicate already-extended ranges
Combine With Your Strategy: Use the statistics as confluence with your technical analysis, support/resistance, or order flow
Customization Options
Trading Sessions Settings
Session Visualization:
Toggle each session on/off independently
Customize colors for each session (New York, London, Asia)
Adjust background transparency using "Range Area Transparency" slider (0-100, default 90)
Show/hide session outlines with "Range Outline" checkbox
Each session has three customizable parameters on the same line:
Checkbox to enable/disable the session
Text field to rename the session label if desired
Color picker to select the session's display color
Hit Rate Levels Settings
Master Controls:
"Show Hit Rate Levels" - Master toggle to show or hide all level lines and labels
Individual Level Toggles:
"7-8 AM Midpoint" - Toggle the 7-8 AM hour midpoint level
"Midnight Open" - Toggle the midnight opening price level
"2-3 AM Midpoint" - Toggle the 2-3 AM hour midpoint level
Hourly Level Styling (applies to 7-8 AM Mid, Midnight, and 2-3 AM Mid):
"Hourly Level Color" - Color picker for all three hourly levels
"Hourly Level Line Width" - Thickness of hourly level lines (1-5, default 1)
"Hourly Level Line Style" - Choose between Solid, Dashed, or Dotted lines (default Dashed)
Session High/Low Styling (applies to Asia High/Low and London High/Low):
"Session High/Low Line Width" - Thickness of session extreme lines (1-5, default 1)
"Session High/Low Line Style" - Choose between Solid, Dashed, or Dotted lines (default Solid)
Additional Options:
"Show Session Midpoints" - Toggle display of Asia and London midpoint reference lines (dotted lines that end when each session completes)
"Label Text Size" - Size of percentage labels on all levels (tiny, small, normal, large, default small)
Table Settings
Statistics Table Controls:
"Show Statistics Table" - Master toggle to display or hide the entire statistics table
"Stats Table Position" - Choose from 9 positions on the chart:
Top: Top Left, Top Center, Top Right
Middle: Middle Left, Middle Center, Middle Right
Bottom: Bottom Left, Bottom Center, Bottom Right
"Stats Table Size" - Text size within the table (Auto, Tiny, Small, Normal, Large, Huge, default Small)
"Sessions for Stats Calculation" - Number of historical sessions to use for percentile calculations (5-100, default 50)
Lower values (20-30): More responsive to recent market conditions
Higher values (50-100): More stable baseline, requires more chart history
The table displays "Sessions Captured" to show how many sessions were actually available
Important Limitations and Considerations
1. This Is Historical Data, Not Prediction
The statistics show what happened in the past given similar setups. Markets evolve, regimes change, and past probability does not guarantee future outcomes. A 75% hit rate means that in 25% of historical cases, the level was NOT hit.
2. Chart History Requirements
TradingView imposes data limits:
5-minute chart: Approximately 10 days of history (enough for minimal statistics)
1-minute chart: Approximately 2-3 days of history (insufficient for percentile calculations)
Use 5-minute or higher timeframes to ensure adequate session capture
The table displays "Sessions Captured" (e.g., 18/50) to alert you when your chart history is limited.
3. Session Timing Is Fixed (EST)
All sessions use America/New_York timezone:
Asia: 8PM-2AM
London: 2AM-8AM
NY: 8AM-4PM
These times do not adjust for daylight saving changes in other regions. The definitions match CME NQ futures trading hours.
4. The Statistics Are From 2013-2025 Data
The 12-year analysis period includes:
Multiple market regimes (bull/bear/sideways)
Various volatility environments
QE, taper tantrums, COVID, 2022 bear market, 2023-2024 rally
However, it is still a limited sample. Future market structure changes (algorithmic trading evolution, regulatory changes, etc.) may alter these probabilities over time.
5. No Real-Time Calculation
This indicator does not recalculate statistics based on your chart's data. It displays pre-calculated probabilities. The only real-time calculations are:
Which pattern occurred today
Where NY opened relative to London midpoint
Current session ranges and their percentile ranks (based on your chart's recent history)
Statistical Methodology Details
Data Source
Instrument: NQ (Nasdaq-100 E-mini Futures) continuous contract
Timeframe: 1-minute bars
Period: January 2013 - January 2025 (12 years)
Sample Size: 3,132 trading days analyzed
Analysis Approach
Each trading day was classified by overnight pattern (4 types). NY opening position vs London midpoint was determined. For each combination (4 patterns times 2 positions equals 8 scenarios), the following was measured:
How often each level (session highs/lows, hourly midpoints) was touched during 8AM-4PM
Which session extreme (high or low) was hit first
Mean distance from 8 AM open to each level
Session ranges were measured for percentile analysis. All percentages were rounded to two decimal places for display.
Why These Specific Levels?
The levels were not chosen arbitrarily:
Session highs/lows: Natural support/resistance from overnight price discovery
7-8 AM midpoint: The final hour before NY open often establishes the opening range balance point
Midnight open: Represents the "true" start of the trading day (6PM-5PM structure)
2-3 AM midpoint: Captures early London price action balance
Testing showed these levels had the highest and most consistent hit rates across different patterns and setups.
Technical Implementation Notes
Language: Pine Script v5
Drawing Objects: Uses boxes for session visualization, lines for levels, labels for percentages, table for statistics
Performance: Optimized for real-time use with max limits set (500 boxes, 500 lines, 500 labels)
Calculations Per Bar:
Session detection (3 sessions)
Hourly detection (3 hourly periods)
Pattern classification
Conditional probability lookup
Percentile rank calculation (for session ranges)
All heavy statistical analysis was performed offline. The indicator only performs simple lookups and real-time range tracking.
Educational Value
Beyond trading application, this indicator demonstrates:
Conditional Probability: How market context (opening position, overnight structure) dramatically changes probabilities
Mean Reversion Dynamics: Why certain levels (7-8 AM midpoint, midnight) have such high revisit rates
Pattern Recognition: How overnight session relationships create different NY session behaviors
Distribution Analysis: Using percentile ranks instead of parametric statistics for skewed data
Understanding these concepts helps traders develop more sophisticated market models beyond simple "support and resistance."
Final Notes
This indicator is a tool for informed decision-making, not a crystal ball. It answers questions like:
"What typically happens in this setup?"
"How often does price revisit these levels?"
"Is this overnight range unusual?"
It does NOT answer:
"Should I buy or sell right now?"
"Where will price be at 4 PM?"
"What will happen tomorrow?"
Combine these statistics with proper risk management, sound trading strategy, and awareness that any individual day can deviate significantly from historical norms. The power of this indicator lies in providing objective, data-driven context to complement your analysis - not in replacing your judgment.
Impulse OTE Fibonacci & Trend Catcher V2------------IMPORTANT------------
Look at the first 3 options in the input settings. You can change these based on what your trading - crypto, NQ, Forex etc. There are tool tips with the recommended settings there as well.
------------What the trader is supposed to do------------
Wait for an UP or DOWN arrow (trend shift).
Let the indicator lock an impulse and draw the fibs.
When price pulls into OTE, it prints READY.
When confirmation happens, it prints ENTRY.
------------Why it’s useful------------
It’s meant to stop you from:
taking random fibs from random swings,
trading weak/noisy moves,
or entering too early without confirmation.
Instead it forces a simple flow:
Trend → Impulse → Pullback to OTE → Confirmed entry
Inversion ZonesInversion Zones is a simple indicator designed to help identify potential price reversal areas, based on liquidity behavior.
The indicator highlights zones where the market:
approaches an area of interest (Supply or Demand),
takes liquidity above or below that zone,
and shows a possible price reaction.
It does not provide automatic entry signals, but helps traders read market context and understand where the price may react, leaving the final trading decision to the trader.All the indicator parameters are fully adjustable, allowing it to be adapted to:
your own trading style,
the timeframe you use,
and the market you trade.
Each trader can choose whether the indicator should be:
more conservative or more reactive,
more focused on market context or on timing.
1m sweep entry helperThis script is designed to aid in sweep trades where the intention is to mean revert after grabbing sellside of buyside liquidity. This script specifically helps with identifying 1m pivot liquidity and targets for the trades.
Moonboys BTC Liquidation Heatmap═════════════════════════════════════════════════════════════
MoonBoys BTC LIQUIDATION HEATMAP
═════════════════════════════════════════════════════════════
Visualize high-probability liquidation zones across Bitcoin futures markets using multi-exchange data and algorithmic pivot detection.
═══ OVERVIEW ═══
This indicator tracks where leveraged positions cluster and highlights areas where cascading liquidations are likely to occur. By combining Open Interest data from major exchanges with volume-weighted pivot analysis, it shows you where the market's leverage is stacked before price gets there.
Perfect for:
• Anticipating volatility zones
• Identifying potential reversal areas
• Avoiding stop-hunt regions
• Confirming breakout/breakdown levels
═══ KEY FEATURES ═══
🎨 HEAT-MAPPED LIQUIDATION ZONES
└─ Green zones = Long liquidations (below price)
└─ Purple zones = Short liquidations (above price)
└─ Color intensity = Volume significance
⚡ SMART SIGNIFICANCE DETECTION
└─ Top 30% of levels automatically highlighted
└─ Lightning bolt icon (⚡) marks critical zones
└─ Enhanced with borders, brighter colors, and bold labels
└─ Weak levels stay subtle to reduce noise
📊 MULTI-EXCHANGE DATA
└─ Binance Futures Open Interest
└─ Bybit Futures Open Interest
└─ Coinbase Spot Volume
└─ Toggle exchanges individually
🕐 MULTI-TIMEFRAME COMPATIBLE
└─ Works on all timeframes: 1m to Monthly
└─ Auto-adjusts filters and aggregation per timeframe
└─ Consistent performance across different chart scales
🎯 CLEAN VISUAL DESIGN
└─ Labels positioned right of chart (off candles)
└─ Connector lines show which label belongs to which zone
└─ Hit levels fade automatically
└─ Only active zones are labeled
═══ HOW TO READ IT ═══
┌─────────────────────────────────────────────────────────┐
│ ZONE TYPE │ MEANING │
├─────────────────────────────────────────────────────────┤
│ 🟢 Green (below) │ Long liquidation cluster │
│ │ → Potential bounce/support zone │
├─────────────────────────────────────────────────────────┤
│ 🟣 Purple (above)│ Short liquidation cluster │
│ │ → Potential rejection/resistance │
├─────────────────────────────────────────────────────────┤
│ ⚡ With icon │ Top 30% most significant levels │
│ │ → Higher probability of reaction │
└─────────────────────────────────────────────────────────┘
═══ TRADING APPLICATIONS ═══
📈 TREND CONTINUATION
→ Price rejects from liquidation zone = trend strength
→ Watch for bounces at green zones in uptrends
→ Watch for rejections at purple zones in downtrends
🔄 REVERSAL SETUPS
→ Price diving into dense liquidation clusters
→ Heavy volume + liquidation zone = potential turning point
→ Combine with momentum divergence for confirmation
⚠️ RISK MANAGEMENT
→ Avoid entries near untouched significant levels
→ High probability of stop hunts and slippage
→ Wait for price to sweep and confirm before entry
🧩 CONFLUENCE TRADING
→ Layer with support/resistance
→ Combine with volume profile nodes
→ Use alongside order flow indicators
→ Validate with moving averages or trend tools
═══ SETTINGS GUIDE ═══
📡 DATA FEEDS
├─ Binance Futures OI: Toggle Binance data
├─ Bybit Futures OI: Toggle Bybit data
└─ Coinbase Spot Vol: Toggle Coinbase data
🔍 LIQUIDATION DETECTION
├─ Lookback Bars (100-2000): Historical scan range
├─ Pivot Width (1-20): Detection sensitivity
│ └─ Higher = fewer, stronger levels
├─ Target Leverage Tier: Distance from pivot
│ ├─ 25x-50x: 2-4% zones
│ ├─ 50x-100x: 0.8-2% zones (default)
│ └─ 100x+: 0.3-0.8% zones
├─ Min Activity Filter: Remove weak signals
└─ Extend Levels (0-200): Project zones forward
🎨 VISUAL OPTIONS
├─ Long/Short Colors: Customize zone colors
├─ Heat Contrast (0.1-3.0): Intensity scaling
├─ Significance Threshold (0.3-0.95): Top % to highlight
├─ Touched Transparency: Fade amount for hit levels
└─ Label Offset: Distance from chart edge
═══ HOW IT WORKS ═══
1. PIVOT IDENTIFICATION
Scans historical data for swing highs/lows using pivot detection
2. VOLUME AGGREGATION
Combines Open Interest + Volume at each pivot point
Creates weighted metric for liquidation probability
3. ZONE PROJECTION
Calculates liquidation bands based on selected leverage tier
Projects zones where stop losses are likely stacked
4. SIGNIFICANCE RANKING
Normalizes all levels against historical range
Top percentile gets enhanced visual treatment
5. REAL-TIME TRACKING
Monitors price interaction with each zone
Active zones extend forward | Hit zones fade and lock
Memory management removes outdated levels
═══ BEST PRACTICES ═══
✅ DO:
• Use on high-liquidity BTC pairs (BTCUSDT, BTCUSD)
• Combine with volume and order flow analysis
• Look for confluences with key technical levels
• Use higher timeframes for more reliable zones
• Adjust leverage tier based on market volatility
❌ DON'T:
• Trade liquidation zones blindly without confirmation
• Ignore broader market context and trend direction
• Overtrade every single level that appears
• Use as sole entry/exit criteria
• Forget proper position sizing and risk management
═══ TECHNICAL NOTES ═══
• Built with Pine Script v6
• Max 500 boxes, 100 labels for optimal performance
• Auto-scales for different timeframe data availability
• Uses request.security() for multi-exchange aggregation
• Dynamic memory management prevents chart lag
═══ DISCLAIMER ═══
This indicator visualizes potential liquidation zones based on historical volume and open interest data. It does NOT:
• Predict future price movements with certainty
• Guarantee reversals or continuations
• Provide buy/sell signals
• Replace proper risk management
Liquidation zones show where leverage is concentrated — not where price will definitely react. Always use this tool as part of a comprehensive trading strategy alongside technical analysis, risk management, and market context.
📚 EDUCATIONAL USE ONLY | NOT FINANCIAL ADVICE
═══ RESOURCES ═══
Pine Script Documentation
→ www.tradingview.com
Understanding Liquidations
→ academy.binance.com
Open Interest Data
→ www.coinglass.com
Leverage Trading Education
→ www.investopedia.com
═══════════════════════════════════════════════════════════
Built for the Bitcoin trading community 🚀
Because knowing where the leverage sits is half the battle 💎
═══════════════════════════════════════════════════════════
HVN Boundary Assist FRVP + ATR Tempo Auto TF Defaults (LOCKED)This indicator is a structure-assist tool, not a signal generator. It is designed to standardize High-Volume Node (HVN) boundary placement and evaluation when using TradingView’s Fixed Range Volume Profile (FRVP) on weekly and monthly timeframes.
The script does not attempt to discover HVNs automatically. The trader selects the HVN visually using FRVP and inputs the HVN center (effective VPOC). From there, the script applies consistent, rules-based logic to define boundaries, track interaction, and prevent lower-timeframe levels from conflicting with higher-timeframe structure.
What the indicator does
1. Standardizes HVN boundary placement
Using the active timeframe’s ATR, the indicator identifies the first candle that regains tempo on each side of the HVN center.
A valid boundary requires:
A bar range ≥ a fixed fraction of ATR
A close that breaks prior rotational overlap
The close of that candle becomes the candidate HVN high or low. Wicks are ignored for structure.
2. Automatically adapts to timeframe
The indicator enforces locked system defaults:
Weekly: 0.33 ATR expansion, 10-bar overlap lookback
Monthly: 0.25 ATR expansion, 8-bar overlap lookback
These values adjust automatically based on chart timeframe, eliminating discretionary tuning.
3. Tracks retests without redefining structure
HVN interaction is tracked via wick touches within a tight ATR-based tolerance.
Retests are informational only and never move boundaries. This captures recognition and rejection behavior without violating close-based structure rules.
4. Ranks HVN strength (0–3)
Each HVN is scored using:
Tightness relative to ATR
Relative volume confirmation
Presence of at least one retest
This produces a simple, comparable strength ranking without overfitting.
5. Enforces clean monthly → weekly nesting
An optional monthly gate restricts weekly logic to operate only inside a defined monthly HVN.
If conflicts arise, monthly structure always overrides weekly, preventing level overlap and structural ambiguity.
What the indicator does NOT do
It does not read FRVP data (TradingView limitation)
It does not auto-detect HVNs
It does not generate trade signals
It exists to remove subjectivity and inconsistency from HVN boundary placement and evaluation.
Intended use
Apply FRVP and visually identify the HVN
Enter the HVN center price into the indicator
Let the script define precise boundaries and interaction metrics
Use monthly HVNs as structural rails and weekly HVNs for execution
Design philosophy
Structure is defined by closes and volatility, not wicks
Retests measure recognition, not acceptance
Higher timeframe structure always dominates
This tool enforces those rules mechanically so the trader doesn’t have to.
NQ Implied Range GovernorThis Pine Script v6 indicator, “NQ Implied Range (VIX ÷ √N) Governor”, builds a real-time implied range framework for Nasdaq futures by importing a volatility index (default CBOE:VXN) on a user-selected timeframe and smoothing it with an EMA. It converts the annualized vol reading into a daily 1σ percentage move via oneSigmaPct = (VIX ÷ √252)/100, then maps that into a point-based implied move from a session “anchor” price. The anchor is locked at RTH session start (0930–1600 ET by default) based on your chosen mode (RTH Open, prior bar close, or daily open). A band mode selector controls how sigma is interpreted: an “Intraday Range” mode uses √(2/π) (~0.798) as a proxy for expected max excursion, while close-to-close modes use ±1σ or ±2σ envelopes; a separate calibration multiplier lets you widen/tighten the bands beyond theory.
Once the implied move is computed, the script plots the upper/lower 1.0 bands, the anchor midline, and optional fills above/below the anchor. It then derives symmetric Fibonacci retracement levels between the anchor and each band (.236, .382, .500, .618, .786) and optional extensions (1.272, 1.618), with right-edge price labels for quick reading. In parallel, it tracks realized RTH range (session high–low) and compares it to the implied total range to produce a “range spent” ratio, dynamically color-coded from green → yellow → orange → red as the session consumes volatility budget. That ratio drives a session-end summary label (realized vs implied, bands, % spent), a configurable dashboard table showing model inputs/outputs (smoothed vol, raw σ%, anchor, ± bands, total range, realized, remaining, distance to bands), and a set of alert conditions for key events: crossing spent thresholds (70/100/120%), touching outer bands, touching key fib levels, extension hits, and session start/end.
OF CVD Divergence Labels (Lite) by TheActualSnailCVD Divergence (Order Flow Proxy) — Lite
This indicator highlights price vs Cumulative Volume Delta (CVD) divergences directly on the price chart, using a lower-timeframe intrabar volume approximation and optional Open Interest (OI) confirmation.
It is designed to catch potential exhaustion, absorption, and early trend shifts, without cluttering the chart with extra panes or lines.
How it works
1️⃣ Intrabar Delta (Order Flow Proxy)
Volume is decomposed on a lower timeframe (e.g. 30s, 1m).
Each intrabar candle contributes volume to buying or selling pressure based on price movement.
This produces a delta (buy − sell volume).
Delta is accumulated into CVD, optionally reset on a higher timeframe (Daily / Weekly / Monthly).
This is not exchange-level footprint data — it’s a robust proxy that works on any TradingView symbol.
2️⃣ Pivot-Based Divergences
The script detects divergences using confirmed swing pivots:
Bullish Regular Divergence
Price makes a lower low
CVD makes a higher low
→ Suggests selling pressure is weakening
Bearish Regular Divergence
Price makes a higher high
CVD makes a lower high
→ Suggests buying pressure is weakening
Optional hidden divergences (continuation-type) can also be enabled.
All labels are plotted at the actual pivot bar, not repainting forward.
3️⃣ Open Interest filter (optional)
When enabled:
Labels are filtered by OI trend direction
You can require:
Rising OI (participation increasing)
Falling OI (position unwinding)
This helps reduce signals caused by low-liquidity noise or passive price movement.
Settings used (shown in screenshots)
These are the settings I personally use for cleaner, more precise pivot labels:
Lower TF (intrabar): 30s
Improves delta accuracy and reduces false divergences
CVD reset: Daily
Keeps CVD context relevant to the session
Pivot length: 5
Good balance between signal frequency and reliability
Use wicks for pivots: ✅ ON
Captures true extremes where absorption often happens
Min CVD diff filter: 0
No artificial filtering — rely on structure + confluence
Show hidden divergences: ❌ OFF
Focus on reversal-type signals
Enable OI filter: ✅ ON
Adds participation context
OI trend length: 5
Short-term confirmation without lag
Filter labels by OI: None
View all signals first, then judge context manually
How to use it (important)
This indicator is not a standalone trading system.
Best used together with:
Market structure (HH / HL / LL / LH)
Key levels (HTF levels, VWAP, range highs/lows)
Liquidity concepts (sweeps, equal highs/lows)
Volume behavior & session context
Divergence ≠ immediate reversal.
Think of it as a context tool, not an entry button.
⚠️ Disclaimer
This indicator is provided for educational purposes only.
It is not financial advice and should not be used on its own to make trading decisions.
Always combine with other confluences and proper risk management.
Floating FibFib will lock onto last traded price and float until you enter, then click Trade Entry and the entry price and it stays locked while your trade progresses
Global OrderFlow CVD Div (USDT+USD + Multi-OI) [TheActualSnail]Global OrderFlow CVD Div (USDT+USD + Multi-OI)
Global OrderFlow CVD Div is a multi-venue order flow proxy that aggregates CVD (Cumulative Volume Delta) from several exchanges (USDT perpetuals + USD spot) and prints pivot-based divergence labels on the price chart. Optionally, it can filter those divergence labels using Open Interest (OI) trend for extra confluence.
This is designed as a “global read” of participation: perps for positioning, spot for real flow, and OI for leverage context.
What this indicator shows
1) Delta (Orderflow proxy)
Because true bid/ask orderflow isn’t available natively in Pine for most markets, this script uses an intrabar OHLCV proxy:
If intrabar close > open → volume counted as “buy”
If intrabar close < open → volume counted as “sell”
If doji → it falls back to close vs previous close
This happens on a Lower TF (intrabar timeframe), then sums intrabar volume inside each chart candle.
2) CVD (Cumulative Volume Delta)
CVD is the cumulative sum of Delta:
Positive CVD suggests net aggressive buying (proxy)
Negative CVD suggests net aggressive selling (proxy)
You can plot:
AVG CVD (aggregated signal)
Optionally each exchange’s CVD separately (debug / comparison)
3) Divergence labels (pivot-based)
The script marks divergences at confirmed pivots:
Regular Bullish Divergence (Bull Div)
Price makes a Lower Low
CVD makes a Higher Low
Regular Bearish Divergence (Bear Div)
Price makes a Higher High
CVD makes a Lower High
Optional:
Hidden Bullish Divergence (trend continuation type)
Price makes a Higher Low
CVD makes a Lower Low
Hidden Bearish Divergence (trend continuation type)
Price makes a Lower High
CVD makes a Higher High
All labels are drawn at the pivot candle (the pivot is confirmed after Pivot length bars).
Inputs & settings explained
Calculation
Lower TF for intrabars
Sets the timeframe used to build the intrabar delta proxy (ex: 30s / 1m / 3m).
Smaller = more precise, but heavier CPU.
Delta mode
Delta = raw (buy vol − sell vol)
Delta % = delta normalized by total intrabar volume (helps when mixing sources with different volume scales)
CVD reset
Controls when CVD is reset back to 0:
None = continuous cumulative
Daily / Weekly / Monthly = resets at timeframe boundary
Fixed time = resets at a specific hour/min in your chart’s timezone
Session (regular) = uses TradingView’s regular session start
Fixed time hour / min (only used when reset = Fixed time)
CVD Sources (USDT perps + USD spot)
Each source has two controls:
✅ Checkbox = enable/disable that venue in the aggregation
Symbol picker = the actual TradingView symbol used
Defaults include:
USDT perps (Binance/Bybit/OKX/Bitget)
USD spot (Binance USD, Coinbase USD, optionally Kraken/Bitstamp)
Blend method
Average = normalizes by number of enabled sources (recommended for “global” confluence)
Sum = adds them directly (can overweight high-volume venues)
Tip: If a symbol is invalid on your TradingView plan/region, just disable it or change it to a valid ticker.
Open Interest (Perps only)
OI is optional and used as a divergence “filter” (not required).
Enable OI filter = turn OI logic on/off
Per-exchange OI toggles + symbol pickers (Binance/Bybit/OKX/Bitget)
OI blend
Average = average OI from enabled sources (recommended)
Sum = summed OI
OI trend length
Lookback for rising/falling detection
Filter labels by OI
None = no filter
Require OI Rising = only show divergence labels when blended OI is rising
Require OI Falling = only show divergence labels when blended OI is falling
Note: Coinbase has no OI feed here, so OI is perps-only by design.
Divergences
Enable divergence labels = on/off
Pivot length = pivot strength (higher = fewer, stronger signals; lower = more signals)
Use wicks for pivots
ON = pivots use High/Low (more sensitive)
OFF = pivots use Close (more conservative)
Min CVD difference (filter)
Requires the CVD pivot value to differ from the previous CVD pivot by at least this amount.
Also show hidden divergences
Enables hidden divergence labels.
Visuals
Show AVG Delta histogram (pane) = plots aggregated delta columns
Show AVG CVD (pane) = plots the aggregated CVD line
Show each CVD (pane) = plots each venue’s CVD line (useful for checking alignment)
Show AVG OI (pane) = plots blended OI (if enabled)
Show zero line (pane) = plots the 0 baseline
Up/Bear colors = colors used for plots and labels
“Icons” you see in the Inputs panel
TradingView uses common UI controls:
✅ Checkbox → enable/disable a feature or a specific exchange/OI feed
🔽 Dropdown → choose modes like Reset type / Delta mode / Blend method / OI filter
🕒 Timeframe selector → choose Lower TF for intrabars
🎨 Color swatch → change label/plot colors
✏️ Symbol picker → choose the exact exchange ticker used by the script
How to use it (practical workflow)
Pick your sources
Keep 2–4 major venues enabled for clean signal (ex: Binance/Bybit/OKX + Coinbase).
If you see “Invalid symbol”, replace the symbol or turn that source off.
Set intrabar precision
Start with 1m lower TF.
If you need more detail and your chart is smooth, try 30s.
Tune divergence sensitivity
Pivot length 5–10 is a good range.
Use wicks ON for earlier signals; OFF for stricter confirmation.
Add confluence
Use the OI filter to avoid divergences that occur with the “wrong” leverage context.
Combine with HTF levels, market structure, liquidity zones, VWAP/POC/NPOC, etc.
Important notes / limitations
This is a proxy, not true bid/ask delta.
Different exchanges report volume differently; aggregation helps but won’t be perfect.
Pivots are confirmed, so labels appear after the pivot is formed (pivotLen bars later).
More enabled sources + smaller intrabar TF = heavier calculations.
Not financial advice
This indicator is for educational/informational purposes only and does not constitute financial advice. Markets are risky. Always validate signals with other confluences, use proper risk management, and make your own decisions.
BOS/CHoCH Impulsive Move Detector #12.2Includes all updates. This indicator includes all BOS & CHoCH impulses and identifies impulses of greater than 5% and differentiates between longs and shorts.
FVG w/ Correlated ConfirmationThis Pine Script indicator detects Fair Value Gaps (FVGs) on your chart—price gaps between candles where no trading occurred, often signaling potential support or resistance zones. It highlights bullish FVGs (gap ups) and bearish FVGs (gap downs) as colored boxes directly on the chart. The indicator also optionally confirms these FVGs by checking if a correlated asset (e.g., NASDAQ:NDX) shows a similar FVG, increasing confidence. Midpoint lines inside the boxes can be displayed to mark the center of the gap.
Boxes are anchored to the exact candles where the FVG forms and extend rightwards by a user-defined number of bars, remaining fixed and not sliding as new bars form. Correlated FVGs add an extra layer of confirmation from related markets, improving reliability and reducing false signals.
Pivots Double Top/Bottom - NancyPsTitsOriginal script taken and converted from HeWhoMustNotBeNamed excellent original script. converted from pine v4 to pine v6 and added alerts for LL, LH, HH, HL for any time frame
// Modified to include HH/HL/LH/LL alerts with timeframe selection
MT Trading Smart MoneyMT Trading 'Smart Money'
MT Trading SM is a market analysis tool based on Smart Money Concepts, designed to identify market context, probable price scenarios, and a structured trading plan — without generating direct buy or sell signals.
The indicator does not try to predict exact price movements or force entries.
Its purpose is to guide the trader’s decision-making process by clarifying what the market is most likely to do next and under which conditions a trade makes sense.
🔹 What the indicator does
Determines swing market context (bullish / bearish / neutral)
Analyzes market structure (BOS / CHoCH)
Tracks relevant swing order blocks
Evaluates whether price is within Smart Money areas of interest
Provides contextual trade planning, not signals
🧠 Bias / Scenario / Plan Dashboard
Instead of entry signals, the indicator displays an analytical dashboard:
Bias — probable market direction
Scenario — what price is likely to do next
Plan — how the trader should react
Example:
Bias: BEARISH ↓
Scenario: Pullback expected
Plan: Wait for price to return to premium zone and confirm structure
⚠️ Important Notes
No take-profit or risk-reward calculations
No forced entries without structure confirmation
Designed for discipline and patience, not impulsive trading
Best used alongside price action and proper risk management
🎯 Who this tool is for
Traders using Smart Money Concepts
Those who want clarity over prediction
Traders focused on structure and zones, not indicators
Traders who value planning over frequency
🧠 Core Philosophy
Not trading is also a valid decision.
This tool helps identify when the market offers no real advantage and prevents unnecessary trades.
Detect Day's High/Low or Opening Range (mihaifx888)A simple script that automatically detects the high + low of the day.
By default it's set from 01:01am until 10:15am because that's my strategy, but you can set it on any time period you want.
Can be used to detect the NY opening range for example, simply adjust the time.
Enjoy ;)
Farjeat Market Structure Break & OBEasily find Order Blocks where the price may react and show the market structure.
BK AK-PnF Window💥 Introducing BK AK-PnF Window — “P🖥️F” (Point & Figure + Heikin Ashi Tactical Panel) 💥
This is not a cute overlay. This is a floating analysis workstation you pin to the chart—so you can read structure without letting candles hypnotize you.
BK AK-PnF Window does one thing at a professional level:
it compresses signal into symbols — X/O columns, reversals, patterns, Gann counts, trend lines, volume-weighting, HTF alignment, and session context — all inside a clean window you can drag, lock, and scale.
No clutter. No guesswork. Just structure.
🎖 Respect & Credit
AK — standards, patience, and execution discipline. This tool is built with “no-spam / no-noise” intent: see the truth fast, act only when it’s clean.
G-d — the source of wisdom, restraint, and right timing. A trader survives by humility: measure first, speak last, act only when the measure is honest.
DskyzInvestments — Window-style layout / floating panel concept inspired by DskyzInvestments (TradingView profile): www.tradingview.com
That floating “panel workstation” concept is foundational to this tool’s presentation.
🧠 What BK AK-PnF Window actually is
It’s a dual-mode window:
1) Point & Figure Mode (PnF)
Shows X/O columns built from ATR-sized boxes
Detects column reversals
Prints PnF patterns (double tops/bottoms, triples, catapults, asc/desc structures)
Projects Gann price objectives using:
Horizontal Count (congestion width → breakout target)
Vertical Count (column height → price objective)
Draws classic 45° PnF trend lines
Adds volume-weighted glyphs (opacity/size changes) to separate “real moves” from paper-thin noise
Adds MTF PnF sync to keep you trading in the direction of the bigger machine
2) Heikin Ashi Mode (HA)
Displays HA candles inside the window with:
OB/OS zones
session shading (Asia/London/RTH)
pattern recognition (soldiers/crows, absorption, exhaustion, inside-bar compression, spinning tops, acceleration)
optional divergence (RSI/MFI)
pivots / buy-sell markers
VROC volume spike highlights
One panel. Two realities. Choose your weapon.
⚙️ The Core Innovations (why this one hits different)
✅ Auto ATR Correlation Engine (PnF box size solved)
PnF lives and dies by box size. Too small = noise. Too big = late.
This script tests multiple ATR candidates (7/14/21/34/55 by default), builds 5 PnF streams, then selects the one with the best absolute correlation to price behavior over your lookback.
Translation: it auto-calibrates box size to the instrument’s heartbeat.
✅ Reversal Logic that matters
PnF reversals are not “candles changed color.”
They require real counter-pressure: N boxes against trend.
So a reversal signal in this window is structural, not emotional.
✅ Pattern Recognition (PnF) = objective structure calls
PnF patterns are pure supply/demand footprints:
Double/Triple tops = resistance tests → breakout logic
Double/Triple bottoms = support tests → breakdown logic
Asc/Desc triples = rising demand / rising supply
Catapults = compound breakouts (rare, powerful)
The script highlights them and attaches tooltips that explain exactly what fired.
✅ Gann Counts on PnF (the projection engine)
This is where it turns from “charting” into “targeting.”
Horizontal Count: congestion width → projected move
More columns = more stored energy.
Vertical Count: column height → projected move
First impulse often defines the objective.
And it plots target lines so you stop trading blind.
✅ 45° Trend Lines (PnF geometry)
Classic PnF discipline: the 45° line is your trend integrity line.
If price can’t hold the bull support line, the “trend story” is over.
✅ Volume-weighted glyphs (conviction meter)
PnF is clean, but it can be deceptive if volume is dead.
So X/O glyphs can be weighted by volume:
Opacity mode: heavy volume pops, light volume fades
Size mode: heavy volume prints bigger
You instantly see whether a column is institutional or hollow.
✅ MTF PnF Sync (higher timeframe alignment)
It builds PnF direction on a higher timeframe and prints an icon:
Confluence = highest probability
Disagreement = caution, HTF usually wins
🧾 Signal Legend (what you’ll see)
PnF Mode
X column = bullish structure
O column = bearish structure
⟳X / ⟳O = reversal into new column direction
Pattern highlights = detected breakout/breakdown structures
Gann target lines = horizontal + vertical projected objectives
45° lines = trend integrity rails
HTF icon = higher timeframe PnF direction alignment
HA Mode
Candles + OB/OS zones + session shading
Pattern markers (institutional-grade)
Optional divergence markers
VROC highlights (volume spike intent)
🎯 How to use it (execution rules)
1) PnF is the truth filter
Use PnF when you want structure without candle noise:
trade breakouts from congestion (H-count)
manage toward objectives (V-count + H-count)
obey 45° lines for trend health
2) MTF Sync = permission
If HTF PnF agrees with your current direction, you can size up.
If it doesn’t, you either:
trade smaller
or wait for alignment
3) Volume-weighting = conviction
Big glyphs / low transparency = real participation.
Faded glyphs = don’t overtrust the move.
4) HA mode is timing + context
Use HA window when you need:
session-based behavior (Asia/London/RTH)
absorption/exhaustion signals
compression tells before expansion
divergence warnings
🔧 Settings that actually matter
PnF Reversal (boxes): strictness of reversals
ATR candidates + lookback: box-size auto calibration quality
Max rows + column spacing: readability vs detail
Pattern tolerance (boxes): how strict “equal highs/lows” must be
Gann congestion tolerance: how wide the zone can be and still count
Volume weighting mode: conviction readout
MTF timeframe + ATR/reversal: higher timeframe authority
Window lock/anchor/height mode: panel ergonomics
👁️ The Watchman Lens — “Guard the Gate”
A watchman doesn’t predict. He observes, confirms, then sounds the alarm only when it’s real.
That’s what BK AK-PnF Window is:
PnF confirms whether structure is real.
Gann counts define where the structure wants to resolve.
Volume weighting reveals whether power is behind it.
HTF sync tells you if the higher command agrees.
The watchman doesn’t get emotional about a candle.
He guards the gate until the signal is undeniable.
Respect to AK for the discipline.
All praise to G-d for the wisdom to wait, and the restraint to act only when the measure is clean. 🙏
Intraday Refuges/Shelters (RID)==========================================
RID (INTRADAY SHELTERS/REFUGES) INDICATOR
==========================================
*Fair warning: this may be more words than a humble, simple indicator truly
needs… but Claude insisted.
// ** INTRODUCTION ** //
RID (Intraday Shelters/Refuges) is a lightweight, fast, and easy-to-implement
indicator designed for monitoring price action on intraday timeframes — the same
ones used by institutional operators to execute their trades within each market session.
The indicator generates a framework of support and resistance levels automatically
calculated from the asset's Daily Opening Price (D.O.P.). These levels are established
using fixed percentages that have proven their effectiveness in institutional trading
for decades, constituting "textbook" references widely adopted by market professionals.
RID integrates as an optional module within our Weekly Shelters (RS) indicator, allowing
the operator to simultaneously control their weekly positions and, when conditions warrant,
move down to intraday operations without loading additional indicators or losing sight
of the higher timeframe.
// ** INDICATOR FUNDAMENTALS ** //
The foundation of RID rests on a proven market principle: the daily opening price acts
as a "psychological anchor" that influences participant behavior throughout the entire session.
Why does this method work?
• UNIVERSAL REFERENCE POINT: The daily opening price is objective data, visible to all
market participants simultaneously. Institutions, algorithms, and retail traders use it
as a common reference to calibrate their decisions.
• STANDARD PERCENTAGE LEVELS: The percentages used (0.382%, 1.0%, 1.5%, 2.0%, 2.5% and
extensions) are not arbitrary. They represent intraday volatility thresholds that have
historically acted as inflection points across multiple asset classes.
• SELF-FULFILLING PROPHECY EFFECT: When a critical mass of operators place orders at the
same percentage levels —whether for profit-taking, protective stops, or entries—
these levels become high-probability price reaction zones.
• INSTITUTIONAL RISK MANAGEMENT: Institutional trading desks frequently define their daily
loss limits and profit targets in percentage terms relative to the open. RID captures
this logic and makes it visible for retail operators.
The ±0.382% level deserves special mention: it's a derivation of the Fibonacci golden ratio
(0.382) applied to the intraday context, representing the first significant movement threshold
from the opening.
// ** INDICATOR OBJECTIVES ** //
1) Facilitate manual intraday trade execution by providing a framework of target prices
established under a scheme of mathematical certainty, eliminating subjectivity in
defining entries, exits, and stops.
2) Serve as a lightweight and modular tool, easily integrable —either as an overlay or
source code— with strategies and indicators specialized in intraday trade execution,
both manual and automated.
3) Provide a visual reference framework that allows the operator to quickly assess the
intraday market "temperature": Is price near a key support or resistance? Has it already
reached the session's typical movement target? Is it time to seek entries or protect profits?
// ** INDICATOR TECHNICAL FEATURES ** //
• 21 CONFIGURABLE LEVELS: 11 main levels (±0.382%, ±1.0%, ±1.5%, ±2.0%, ±2.5% and D.O.P.)
plus 10 extended levels (±3.0% to ±5.0%) for high volatility sessions. Each level can
be individually enabled or disabled according to operator needs.
• AUTOMATIC D.O.P. DETECTION: The indicator automatically identifies the start of each daily
session and captures the opening price without user intervention.
• CONFIGURABLE HISTORY LIMIT: Option to limit processing to the last N days (default: 3),
optimizing performance on very low timeframes (1m, 5m) where excess historical data can
slow down the chart.
• PROFESSIONAL VISUALIZATION: Labels with formatted price (thousands separators) and
percentage, placeable with configurable offset. The D.O.P. level (0%) is highlighted
with differentiated width.
• VERTICAL REFERENCE LINES: From D.O.P. to each level, facilitating visualization of the
percentage distance traveled.
• FULL CUSTOMIZATION: Colors, widths, line styles (solid, dashed, dotted), label opacity,
and forward extension fully adjustable.
• PRICE SCALE INTEGRATION: Levels can be displayed on the right margin of TradingView,
controllable from the indicator's Style tab.
• BAR REPLAY COMPATIBILITY: Works perfectly with Bar Replay for back-testing
intraday strategies.
• OPTIMIZED PERFORMANCE: Efficient architecture with persistent arrays and intelligent
updating, suitable for timeframes down to 1 minute.
// ** OPERATING INSTRUCTIONS ** //
INITIAL SETUP:
1) Load the indicator on a chart with 4H or lower timeframe (1H, 30m, 15m, 5m, 1m).
2) Enable "Limit history by days" and adjust "Maximum days to display" according to your needs:
• For scalping (1m-5m): 1-2 days
• For day trading (15m-1H): 2-3 days
• For intraday swing (4H): 3-5 days
OPERATIONAL USE:
3) Identify the D.O.P. (0% line): This is your central reference point for the session.
4) Observe current price position relative to levels:
• Price above D.O.P. → Session with bullish bias
• Price below D.O.P. → Session with bearish bias
5) Use levels as:
• ENTRIES: Look for reversal signals when price reaches S1-S5 (buys) or R1-R5 (sells)
• TARGETS: Set take-profits at the next resistance level (longs) or support (shorts)
• STOPS: Place protective stops beyond the immediate opposite level
PRACTICAL RULES:
6) The ±1.0% and ±2.0% levels are historically most respected; prioritize them.
7) If price exceeds ±2.5% from open, it might be time to take profits and close your position
or consider enabling extended levels (±3.0% to ±5.0%).
8) High volatility days (news, earnings): wait for price to respect at least one level
before trading in its direction.
9) Combine RID with other indicators from our ecosystem (RS, RMP, RLP/RLPS) to confirm level
confluence across multiple timeframes.
VISUAL OPTIMIZATION:
10) For clean charts: keep enabled only main levels (±0.382% to ±2.5%).
11) For detailed volatile asset analysis: also enable extended levels.
12) Adjust "Label margin" to prevent overlap with current price.
// ** INTEGRATION WITH OTHER SHELTER VALUE INDICATORS ** //
RID is part of a complete shelter-based analysis ecosystem we have developed:
• RLP (Long-Term Shelters): For automatic determination of the preponderant phase
of a Zigzag, which institutional investors choose as the base of a Fibo whose
levels calculate order placement projection over the following months and years.
• RLPS (Simplified Long-Term Shelters): Simplified version of RLP where known
coordinates of the preponderant phase are captured, obtained through own analysis
or automatically with the RLP indicator.
• RMP (Medium-Term Shelters): Provides psychological shelter and resistance levels
that institutional investors establish at the beginning of each year. They
constitute the main framework used by professionals to plan operations
throughout the year.
• RS (Weekly Shelters): For short-term tactical analysis (4H, 1H) based on selected
phases of one or two Zigzags that define Fibo tracing, over recent major and minor
degree pauses, whose levels take effect during the current and following weeks.
• RID (Intraday Shelters): This indicator. For intraday operations based on levels
calculated from daily opening price, designed for 4H or lower timeframes,
including scalping strategies.
By combining RID with RLP/RLPS, RMP and RS, a multilevel scaffolding is built that
allows trading with clarity on any time horizon, from minute positions to operations
projected over months and years.
// ** NOTES ** //
• All comments regarding detected errors and improvement suggestions are welcome and deeply appreciated. Your feedback helps us refine these tools.
• To our Hispanic speaking friends, we sincerely regret to inform you that we have not
included the Spanish translation in the published version, due to our latent concern
regarding the ambiguous rules about prohibitions on publishing indicators documented
or described in languages other than English.
• Sharing is motivating because there’s no better way to receive genuine feedback
of real acceptance.
• RECOMMENDED VALIDATION METHOD: Use TradingView's Bar Replay to verify, session by
session, how price of your favorite asset interacts with RID levels. This personal
validation will give you statistical confidence before incorporating the indicator
into your actual trading.
Happy hunting in this magnificent jungle!
Auto 1HR Level )Auto level 1 hr. pre market H/L opening print
Yes, the script updates automatically with price action. Here's how each level works:
Blue S/R Levels:
Updates in real-time during RTH (Regular Trading Hours)
New levels are created when your candle pattern rules are met
Old levels beyond your lookback period (1 days default, extends to 120days at extremes) are automatically removed
Broken levels are deleted when price closes through them
Red Premarket Levels:
Resets every new trading day
Tracks premarket high/low from 4:00 AM to 9:30 AM
Draws the levels when RTH starts at 9:30 AM
Green Opening Candle Level:
Resets every new trading day
Places level on the first RTH candle each day
So yes, as long as you have the indicator on your chart, it will continuously update with live price action - no manual refresh needed.
PDH(RTH)+PMH / PDL(RTH)+PML First Break + 3m EMA Retest + TPshows pre market levels, previous day levels, includes the 3min 9ema for the retest and a take profit indicator.
Wolf Alpha Sentinel🎯 Why Wolf Alpha Sentinel?
-BOS & CHoCH Triggers: Break of Structure (BOS) and Change of Character (CHoCH) are not just labels; they are the core trading signals that mark the start of a trend or a true shift in market direction. Thanks to the displacement filter, only real, high-volume breakouts are highlighted.
-Deep Reversal Zone (1.272 – 1.414): Goes beyond standard Fibonacci levels. The 1.272 – 1.414 range—where price sweeps liquidity and reaches an “extreme overbought/oversold” condition—is marked as the most critical reversal area.
-Optimal Trade Entry (OTE): Automatically boxes the institutional pullback zones between 0.62 – 0.79.
-Mitigation Logic: Tested zones fade out visually, allowing you to instantly see which areas are still fresh and actionable.
🐺 Sniper Strategy: 55-Minute HTF + 3-Minute LTF
To extract maximum performance from this indicator, a Top-Down Analysis approach is recommended:
-Macro Bias (55 Minutes): The indicator continuously tracks the 55-minute market structure in the background. When you see a BOS or CHoCH label on your chart, you are officially a “hunter” in that direction.
-Entry Timeframe (3 Minutes): Once the primary direction is defined, switch your chart to the 3-minute timeframe.
-Deep Liquidity Hunt: Wait for price to retrace into the 1.272 – 1.414 (Deep Reversal) or OTE zones defined by the 55-minute structure, using 3-minute candles.
-Trigger: When price taps into these deep zones, execute the trade based on a micro structure break or a clear candlestick formation on the 3-minute chart.
Why 55m & 3m?
-55 Minutes: Reveals the true intentions of large players (Smart Money) and filters out market noise.
-3 Minutes: Tightens your stop distance and maximizes your risk-to-reward ratio. Entering on the 3-minute chart from a 55-minute zone is like riding an elephant with the risk of an ant.
💡 Strategy Summary
This indicator is built on the logic of price clearing liquidity in the 1.272 – 1.414 zone and then joining the main trend through a BOS/CHoCH continuation move.
Group 2: Weekly Regime ClassifierThis indicator classifies the weekly market regime inside monthly value so you know whether to rotate, wait, prepare for expansion, or stand aside before looking for daily trades.
Purpose: Decide whether the market is rotating, compressing, attempting to escape value, or should be avoided entirely.
What this script does
This script analyzes weekly price behavior in the context of your manually defined monthly value area. Its job is to classify the current weekly regime so you know which type of trade logic is even allowed, before you look at daily setups.
It answers one question:
“What kind of environment am I dealing with right now?”
It does not generate trades. It does not choose entries or exits. It tells you whether conditions favor:
value rotation,
expansion attempts,
waiting, or
standing aside due to instability.
How it works (in simple terms)
The script always evaluates weekly candles, even if you apply it to a daily chart.
It uses four ideas:
1. Monthly value containment
All weekly analysis is framed by your monthly VAH and VAL.
If weekly closes are outside monthly value, that matters.
If weekly closes are inside monthly value, that matters differently.
The monthly levels are manual inputs and never auto-calculated.
2. Weekly alternation (instability check)
The script checks the last 6 weekly candles:
If most candles flip direction back and forth, the environment is unstable.
This is labeled “Neutral – heavy alternation”.
In this state, trades should be skipped unless conditions are perfect.
This acts as a sector-level permission filter.
3. Weekly regime classification
Based on quantified rules, the script assigns one regime:
ROTATING (Roadmap A default)
Price is staying inside monthly value and weekly ranges are normal.
This favors mean-reversion and value-to-value trades.
COMPRESSING (Wait)
Weekly ranges and volume are shrinking while price remains inside value.
This signals energy building, but no trade yet.
ESCAPING (Roadmap B on deck)
Weekly closes cluster near one edge of monthly value and show progress toward breaking out.
This sets up possible expansion trades, pending daily confirmation.
WAIT / NEUTRAL
Conditions do not clearly support rotation or expansion.
No bias is assumed.
4. Edge proximity and progress
The script also reports whether price is:
near monthly VAH,
near monthly VAL,
or not near an edge.
For escaping regimes, it checks that price is actually moving closer to the edge, not drifting sideways.
What you see on the chart
Optional background shading by regime (informational only)
Optional monthly and weekly level lines (display only)
A dashboard showing:
current weekly regime,
alternation status,
edge proximity,
weekly RangeRatio,
weekly VolumeRatio,
flip count,
freshness of weekly levels
Nothing on the chart triggers trades or alerts.
How you’re meant to use it
Run this after Group 1
Group 1 answers: Can I trade at all?
Group 2 answers: What type of trading makes sense?
Use the regime to choose a roadmap
ROTATING → value rotation logic (Roadmap A)
ESCAPING → watch for expansion logic (Roadmap B)
COMPRESSING → wait
NEUTRAL → skip unless exceptional
Only then drop to the daily chart
Daily execution rules apply only if the weekly regime allows them.
What this script deliberately does NOT do
No entries
No exits
No targets
No stop logic
No automatic level calculation
No intraday analysis
It does not tell you what to trade.
It tells you what kind of environment you’re in.
